Adjustable Wall Mounting Bracket
The mounting bracket is used for the bottom end cup and gate receiver and is horizontally adjustable to easily align with the gate frame. It allows them to be mounted to the side of the receiving post for UL325 compliance.
U-Channel Guide Rail Galvanized 1-1/4″ id
| Top Guide Type |
|---|
Steel guide track for side mounted guide rollers. Typically used for gates that have an arched or decorative gate top, protruding pickets, barbed wire, or other top obstructions.
Tension Bars – Stainless Steel for 50mm metric tubing, usa 2-1/2″ sq. min.(shimmed)
The tension bar acts as a turnbuckle and builds in gate adjustability to moderate long term sag and post movement problems. Fits into 50mm square tubing and can be adapted to use in Imperial tubing sizes.
